率能半導體推出SS6208用于電子煙|無線充|玩具|馬達驅動芯片
率能半導體代理商華芯旺，率能半導體一級代理商提供步進電機-直流有刷電機-無刷電機-馬達驅動芯片，完全PIN TO PIN兼容替代
TI德州儀器-NXP恩智浦-Allegro-ST意法-ON安森美-MPS芯源-ROHM羅姆-TOshiba東芝-Infineon英飛凌馬達驅動.
歡迎來電13923807831華芯旺科技咨詢技術選型及索取樣片。
一、率能SS6208用于電子煙|無線充產品概述
The SS6208 integrates a single Phase MOSFET driver,high side MOSFET and low side MOSFET into a3mm*3mm 8-pins DFN
package. The SS6208 integratedsolution greatly reduces the package parasitic effect andboard space compared to a discrete
component solution.
The driver and MOSFETs have been optimized for halfbridge applications. With a wide operating voltage range,the driver voltage
of high or low side MOSFET gate can beoptimized for the best efficiency. Internal adaptive nonoverlap circuit further reduces switching
losses bypreventing simultaneous conduction of both MOSFETs.
The UVLO circuits prevent malfunction when VCC is lowerthan the specified threshold voltage. PIN EN designed forstandby mode
can be used to enable chip into lowquiescent current state and get long battery life time
二、率能SS6208用于電子煙|無線充產品特性
• Max Rated Continuous Current 4A, Peak 8A
• Bootstrapped High-Side Drive
• High/Low Side MOSFET integrated
• High-Frequency Operation (Up to 1MHz)
• PWM Input Compatible of 3.3V and 5V
• Internal Bootstrap Diode
• Under Voltage Lockout
• Internal Thermal Shutdown
• Adaptive shoot through protection
• Small package：DFN3*3, 8pins
• These are Pb-Free Devices
三、率能SS6208用于電子煙|無線充產品應用范圍
• Wireless charger for 5W to 20W systems
• Half-bridge application
